Intermatic ET1125C 24-Hour 30-Amps 2XSPST/DPST Electronic Time Switch, Clock Voltage 120-Volt - 277-Volt NEMA 1

Intermatic ET1125C 24-Hour 30-Amps 2XSPST/DPST Electronic Time Switch, Clock Voltage 120-Volt - 277-Volt NEMA 1 Review

Buy From Amazon.com

Intermatic ET1125C 24-Hour 30-Amps 2XSPST/DPST Electronic Time Switch, Clock Voltage 120-Volt - 277-Volt NEMA 1 Feature

• Program can be repeated on a daily basis
• Multi-volt operation from 120-277 VAC, 50/60 Hz
• To-the-minute programming for accurate load control and reduced energy costs
• Up to 28 set points or events (14 ON/14 OFF per channel) can be preset to automatically repeat on a daily basis
• Automatic Daylight Saving Time adjustment (Factory Enabled)

Enclosure is NEMA 1 gray painted drawn steel. Replaceable AAA batteries, included, maintain date and accurate time keeping for 3 years minimum. Up front replacement does not require removal. Program can be repeated on a daily basis. Multi-volt operation from 120-277 VAC, 50/60 Hz. To-the-minute programming, up to 28 set points or events (14 ON/14 OFF per channel) can be preset to automatically repeat on a daily basis with automatic daylight saving time adjustment. Non-volatile EEPROM memory protects programming indefinitely. Temporary override or permanent manual override with push buttons. Combination 1/2" - 3/4" nominal knockouts, one on back and each side of enclosure and two on bottom. Number 18 to number 10 AWG wiring terminals. Minimum ON/OFF 1 minute, maximum ON/OFF is 23 hours 59 minutes. Switch ratings per pole: 30A inductive/resistive: 24/120/208/240/277 VAC, 60 Hz. 20A ballast: 120-277 VAC, 60 Hz. 20A resistive: 28 VDC. 5 A tungsten: 120/240 VAC, 60 Hz. 1 HP: 120 VAC, 60 Hz. 2 HP: 240 VAC, 60 Hz.
